VERSION LS-201

FEATURES:

• SINGLE SEAL

• UNBALANCED

• INSIDE MOUNTED

• CONICAL SPRING

• DEPENDENT ON DIRECTION OF ROTATION

STANDARD M.O.C.:

• SEAL FACES:

  Carbon
  Stellite
  Ceramic
  Tungsten Carbide
  Silicon Carbide

• SECONDARY SEALS :

  Nitrile
  EPDM
  Viton

• METAL PARTS :

  S.S. 316

APPLICATIONS:
Water Pumps
Chemical Process Pumps
Sewage Pumps
submersible Pumps

OPERATING PARAMETERS:
Sizes:                    12mm to 80mm
Pressure:              Upto 8 bars
Temperature:      -20Deg.C to +130 Deg.C
Speed:                  Upto 20m/s
Axial Movement: +/- 1.0mm

DESCRIPTION
Version LS-201 is a single conical spring, unbalanced seal which is dependent on direction of rotation from the drive-end. This seal is rugged, reliable and covers wide range of applications. Its user friendly, easy to install and maintain
